| BASIC INFO |
| Model No. |
QCOM
W1019 |
| Operating system |
Windows
11 Pro |
| Dimension |
263*177*10.5mm |
| Weight |
674g
(include battery) |
| Material |
PC+10%GF |
| Color |
Black,
white |
| Language |
Multi-language |
| HARDWARE |
| Display |
10.1
inch 16:10 FHD IPS capacitive touch screen, 1920*1200px, 400cd/㎡ |
| Processor |
Qualcomm
SC7180 Kryo 468 8C8T, up to 2.4GHz;
GPU: Adreno 618, 8nm |
| RAM |
8GB
RAM ( LPDDR4X) |
| ROM |
128GB
ROM, support TF card up to 512GB maximally |
| Camera |
Double
cameras: 5.0MP front, 13MP AF rear camera with flashlight |
| Battery |
Built-in
7.6V/4750mAh Li-polymer battery |
| LED indicator |
Red/green |
| Sensors |
G-sensor |
| Speaker |
8Ω/1W
waterproof speaker *2 |
| Keys |
Power
button, Volume -/+, scan button*1 |
| NETWORK
& CONNECTIVITY |
| Network Bands |
2G:
N/A |
| 3G: WCDMA 850/900/1900/2100MHz |
| 4G: FDD-LTE:B1/B3/B5/B7/B8/B20/B28A/B28B,
TDD-LTE: B38/B39/B40/B41 |
| WiFi |
IEEE802.11
a/b/g/n/ac, support 2.4GHz/5GHz dual band WiFi |
| BT |
V5.1 |
| GNSS |
Support
GPS/Galileo/GLONASS/BeiDou |
| I/O
INTERFACES |
| SIM slots |
*2 ( SIM+SIM or SIM+TF) |
| TF card slot |
*1 |
| USB Type-C 3.0 |
*1
(OTG) |
| Pogo Pin |
*1 |
| RELIABILITY |
| Waterproof/Dust-proof |
IP65 |
| Anti-Drop |
1
meters drop |
| Temperature range |
Operating:
-10℃~+50 ℃, storage:-20℃~+60 ℃ |
| OTHER
FUNCTIONS |
| 2D Data Collection |
Built-in
Newland N1: scanning speed: 75 times/s,
recognition accuracy: ≥3mil |
| ACCESSORIES |
| Adaptor (12V/3A) |
*1 |
| Hand strap |
*1 |
| USB cable |
*1 |
| Charging dock |
Optional |
| Leather case keypoard |
Optional |
