| BASIC INFO |
| Model No. |
UNIWA
V5P |
| Operating system |
Android
13 |
| Dimension |
179*74.5*22.5mm
(Printer 49.5mm) |
| Weight |
330g
(including battery) |
| Material |
Plastic |
| Color |
Black |
| Languages |
Multi-language |
| HARDWARE |
| Display |
5.5
inch IPS capacitive multi-touch screen, 1440*720px, 550cd/㎡ |
| Processor |
Mediatek
MT6765 Helio P35 octa core, up to 2.3GHz; GPU: PowerVR Rogue GE8320 |
| RAM |
4GB
RAM |
| ROM |
64GB
ROM, support TF card up to 256GB maximally |
| Camera |
Double
cameras: 2.0MP front camera, 13MP AF rear camera with flashlight |
| Battery |
Removable
7.6V/2750mAh Li-ion battery (equal to 3.8V 5500mAh) |
| Sensor |
Gravity
sensor, light sensor, proximity sensor |
| Speaker |
1W |
| Keys |
Home
key, delete key, back key, confirm key |
| Buttons |
Power
button, Volume +/- , Scan button*2 |
| Thermal Sticker Printer |
Sticker/label
black printing: 70mm/s; 384 dots; 58mm
paper slot; 35mm papar diameter |
| NETWORK
& CONNECTIVITY |
| Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100MHz |
| 4G: FDD-LTE B1/B3/B4/B7/B8/B12/B20; TDD-LTE:
B38/B39/B40/B41 |
| WiFi |
IEEE
802.11 ac/a/b/g/n/d/e/h/i/j/k/r/v protocol, support 2.4GHz/5.0GHz dual-band
WiFi |
| BT |
V5.0
(BLE) |
| GNSS |
Support
GPS/GLONASS/Galileo/BDS |
| I/O
INTERFACES |
| Micro SIM Slot |
*1 |
| TF Card Slot |
*1 |
| USB Type-C Port |
*1,
support OTG function |
| PSAM Slot |
Optional |
| RELIABILITY |
| Waterproof |
IP54 |
| Anti-shock |
1.2
meters drop on marble |
| Temperature range |
Operating: -20℃～+55℃; Storage: -40℃～+70℃ |
| OPTIONAL
FUNCTIONS |
| 2D Barcode Modules |
Optional:
Honeywell N5703 N6703, 6602, Newland E483 |
| ID Card Identification |
Optional |
| NFC |
Optional |
| ACCESSORIES |
| Power Adaptor (5V/2A) |
*1 |
| USB cable |
*1 |
| Protective Film |
*1 |
| User Manual |
*1 |
