| BASIC INFO |
| Model No. |
UTAB
R1033 |
| Operating system |
Android
10 (GMS) |
| Dimension |
275*179.2*21.8mm |
| Weight |
1120g |
| Material |
PC+TPU |
| Color |
Black/Yellow,
can be customized |
| Languages |
Multi-language |
| HARDWARE |
| Display |
10.1
inch 7H anti-scratch IPS touch screen, 1280*800px, 300cd/㎡. |
| Processor |
MT6771
Helio P60 Octa core 2.0GHz (4 cortex-A73 2.0GHz+4 cortex-A53 2.0GHz) |
| RAM |
4GB
RAM, 2GB/6GB optional |
| ROM |
64GB
ROM, 32GB/128GB optional, support TF card up to 256GB maximally |
| Camera |
Double
cameras: front camera 5MP FF, rear camera 13MP AF with flashlight |
| Battery |
Built-in
3.8V/10000mAh Li-ion battery |
| Sensors |
Gravity
sensor, light sensor, proximity sensor, gyroscope, E-compass |
| Speaker |
*2,
1.2W/8Ω, IP67 waterproof speakers |
| Receiver |
*1,
IP67 waterproof |
| Mic |
*1,
IP67 waterproof analog Mic |
| Buttons |
Power
button, Volume+/-, F-key |
| Indicator light |
RGB |
| NETWORK & CONNECTIVITY |
| Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100, CDMA2000 |
| 4G: FDD-LTE
B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B20/B28A/B28B/B66/B71, TDD-LTE:
B38/B39/B40/B41 |
| Wi-Fi |
IEEE
802.11a/b/g/n/ac, 2.4G+5.8G dual-band Wi-Fi |
| BT |
V4.2
(BLE) class1, transfer distance: 10m |
| NFC |
13.56MHz,
support 14443A/14443B/15693 protocol |
| GNSS |
Support
GPS, BDS, Galileo, GLONASS (U-BLOX M8N module is optional) |
| I/O INTERFACES |
| Micro SIM card slot |
*1 |
| TF card slot |
*1 |
| Mini HD-MI port |
*1 |
| 3.5mm earphone port |
*1 |
| USB Type C 2.0 |
*1,
support OTG function |
| 5V/3A DC charging port |
*1,
(5V/3A aviation port optional) |
| Pogo Pin |
12pin
USB + charging |
| OPTIONAL FUNCTIONS |
| Screen |
800cd/㎡
(1920*1200), 1000cd/㎡ (1280*800), wet hand/glove touch, active/passive
capacitve stylus, AG+AF anti-glare plating, AR light-transmitting coating |
| Fingerprint unlock |
1:
Ordinary industrial fingerprint
2: Fingerprint authentication by the Ministry of Public Security
3: FBI certified fingerprint |
| ID card identification |
Support
reading 2th Generation ID card |
| 1D scanning function |
Zebra
SE655 |
| 2D scanning function |
Zebra
SE4710 |
| HF RFID |
13.56MHz,
support 14443A/14443B/15693 protocol |
| UHF RFID |
PR9200,
distance 1: 1.5m-3m, distance 2: 5m-8m; R2000, distance: 10m-18m |
| RELIABILITY |
| Waterproof |
IP67 |
| Drop-proof |
1.2m,
cement floor |
| Temperature range |
Operating:
-20℃~60℃, Storage: -30℃~70℃ |
| ACCESSORIES |
| Charger |
*1 |
| User manual |
*1 |
| Hand strap |
Optional |
| Ball-head car mount |
Optional |
| Dock charger |
Optional |
| Type-C cable |
Optional |
| OTG cable |
Optional |
