| BASIC INFO |
| Model No. |
WinPad
BT301 |
| Operating system |
Windows
10/11 |
| Dimensions |
258*173*8.5mm |
| Weight |
672g
(not included keyboard) |
| Material |
Aluminium
alloy |
| Languages |
English,
Spanish, French, Itailian, Deustch, Portuguese, Russian, Chinese, Korean,
etc. |
| HARDWARE |
| Display |
10.1
inches 16:10 IPS capactive touch screen, 1280*800px (FHD optional) |
| Processor |
Intel
Celeron Processor J4125 4C4T, up to 2.7GHz;
GPU: Intel UHD Graphics 600 |
| RAM |
4GB
or 8GB DDR4L |
| ROM |
64GB
or 128GB eMMc, support Micro SD up to 256GB maximally |
| Camera |
Double
cameras, 2.0MP front camera, 2.0MP AF back camera |
| Battery |
Built-in
7.4V/4500mAh lithium-ion polymer battery |
| Speaker |
*2,
Built-in 8Ω/0.8W speaker |
| NETWORK & CONNECTIVITY |
| WiFi |
IEEE
802.11a/b/g/n/ac, support 2.4GHz/5GHz dual band wifi |
| BT |
V4.0 |
| 4G Module |
Optional |
| I/O INTERFACES |
| Micro SD slot |
*1 |
| φ3.5mm DC port |
*1 |
| USB Type-C 2.0 |
*1 |
| USB Type-A 3.0 |
*1 |
| Mini HD-MI Type-C 1.4a |
*1 |
| 3.5 mm audio jack |
*1 |
| OTHER FUNCTIONS |
| USB to RJ45 |
Support |
| OTG function |
Support |
| Others |
Support
Flash 11、HTML 5、Office etc |
| STANDARD ACCESSORIES |
| AC adaptor (12V/2A) |
*1 |
| User manual |
*1 |
| OTG cable |
*1 |
| Keyboard |
Optional |
